| Spindle Taper |
– |
7:24 ISO50 |
| Distance from Spindle End to Table Surface |
mm |
0-380 |
| Distance from Spindle Center to Vertical Guideway |
mm |
175 |
| Spindle Speed Range |
r/min |
60-1500 (12 steps) |
| Table Size |
mm |
1500 × 360 |
| Table Travel (Long./Cross/Vert.) |
mm |
1000 / 320 / 400 |
| Long./Cross Power Feed Rate |
mm/min |
22-540 (8 steps), Rapid 540 |
| Vertical Power Feed Rate |
mm/min |
590 |
| Table T-slot (No./Width/Pitch) |
mm |
3 / 18 / 80 |
| Overarm Travel |
mm |
500 |
| Main Motor Power |
kW |
4 |
| Long./Cross Feed Motor Power |
W |
750 |
| Vertical Feed Motor Power |
W |
1100 |
| Coolant Pump Power |
W |
90 |
| Coolant Pump Flow |
L/min |
25 |
| Net / Gross Weight |
kg |
2300 |
| Overall Dimension (L×W×H) |
mm |
2250 × 1790 × 1880 |
